CKA Prep - Workloads and Scheduling

This post is part of a series which contains my study notes for the Certified Kubernetes Administrator (CKA) exam.

Note: Unless specifically indicated, text and examples in this post all come directly from the official Kubernetes documentation. I attempted to locate and extract the relevant portions of the kubernetes.io documentation that applied to the exam objective. However, I encourage you to do your own reading. I cannot guarantee that I got all of the important sections.

Workloads and Scheduling

The Exam Curriculum breaks down the second exam topic into the following objectives:

• Understand how resource limits can affect Pod scheduling
• Understand the primitives used to create robust, self-healing, application deployments
• Understand deployments and how to perform rolling update and rollbacks
• Know how to scale applications
• Use ConfigMaps and Secrets to configure applications
• Awareness of manifest management and common templating tools

Understand How Resource Limits can Affect Pod Scheduling

Relevant search terms for Kubernetes Documentation: Resource requirements, requests and limits, limitrange, resourcequota

Kubernetes Documentation Links

• Resource Management for Pods and Containers
• Assign Memory Resources to Containers and Pods
• Assign CPU Resources to Containers and Pods
• Configure Default Memory Requests and Limits for a Namespace
• Configure Default CPU Requests and Limits for a Namespace
• Configure Minimum and Maximum Memory Constraints for a Namespace
• Configure Minimum and Maximum CPU Constraints for a Namespace
• Configure Memory and CPU Quotas for a Namespace
• Configure a Pod Quota for a Namespace
• Limit Ranges
• Resource Quotas

API Objects

• ResourceQuota - a policy which constrains the total resource allocation for all of the resources in a given namespace.
• LimitRange - a policy which constrains resource allocations for individual resources in a given namespace.

Concepts

• When defining the container spec for a pod, you can specify resource requests and limits:

  • “When you specify the resource request for containers in a Pod, the kube-scheduler uses this information to decide which node to place the Pod on.”
  • “When you specify a resource limit for a container, the kubelet enforces those limits so that the running container is not allowed to use more of that resource than the limit you set.
  • “The kubelet also reserves at least the request amount of that system resource specifically for that container to use.”
  • “If you specify a limit for a resource, but do not specify any request, and no admission-time mechanism has applied a default request for that resource, then Kubernetes copies the limit you specified and uses it as the requested value for the resource.”
  • “When you create a Pod, the Kubernetes scheduler selects a node for the Pod to run on. Each node has a maximum capacity for each of the resource types: the amount of CPU and memory it can provide for Pods. The scheduler ensures that, for each resource type, the sum of the resource requests of the scheduled containers is less than the capacity of the node.”
  • If the resource requests of a Pod exceed available resource capacity on all nodes then the Pod will not be scheduled.
  • “Note that although actual memory or CPU resource usage on nodes is very low, the scheduler still refuses to place a Pod on a node if the capacity check fails. This protects against a resource shortage on a node when resource usage later increases, for example, during a daily peak in request rate.”

• There are two types of policies that can be defined for a given namespace to manage resource usage.

  • A Limit Range policy controls resource utilization for the pods and persistent volume claims created in a given namespace.
    • Pod - set minimum and maximum CPU and memory limits. Requests to create pods which do not reside within the defined limits will be rejected.
    • Container - Define default CPU and memory requests and limits. If a container spec does not have CPU or memory requests and limits defined then the policy will inject the default requests and limits defined in the Limit Range into the Pod spec.
    • Container - set minimum and maximum CPU and memory limits
    • Persistent Volume Claim - set minimum and maximum storage. Requests to create persistent volume claims which do not reside within the defined limits will be rejected.
  • “A Resource Quota, defined by a ResourceQuota object, provides constraints that limit aggregate resource consumption per namespace. It can limit the quantity of objects that can be created in a namespace by type, as well as the total amount of compute resources that may be consumed by resources in that namespace.”

Sample YAML Files

• Sample Pod definition YAML file with requests and limits specified:

  apiVersion: v1
  kind: Pod
  metadata:
    name: frontend
  spec:
    containers:
    - name: app
      image: nginx
      resources:
        requests:
          memory: "64Mi"
          cpu: "250m"
        limits:
          memory: "128Mi"
          cpu: "500m"


• Sample Limit Range Policy YAML file

  apiVersion: "v1"
  kind: "LimitRange"
  metadata:
  name: "accounting-limits"
  spec:
  limits:
    - type: "Pod"
      min: # Hard Limit
        cpu: "100m"
        memory: "30Mi"
      max: # Hard Limit
        cpu: "2"
        memory: "2Gi"
    - type: "Container"
      defaultRequest: # Default Request
        cpu: "100m"
        memory: "150Mi"
      default: # Default Limit
        cpu: "350m"
        memory: "300Mi"
      min: # Hard Limit
        cpu: "75m"
        memory: "4Mi"
      max: # Hard Limit
        cpu: "1"
        memory: "1Gi"
      maxLimitRequestRatio:
        cpu: "5"
        memory: "7"
    - type: "PersistentVolumeClaim"
      min:
        storage: "1Gi"
      max:
        storage: "15Gi"


• Sample Resource Quota Definition YAML File

  apiVersion: v1
  kind: ResourceQuota
  metadata:
    name: accounting-quota
  spec:
    hard:
      pods: "20"
      requests.cpu: "1"
      requests.memory: 1Gi
      requests.ephemeral-storage: 5Gi
      limits.cpu: "2"
      limits.memory: 4Gi
      limits.ephemeral-storage: 10Gi
      configmaps: "50"
      count/deployments.apps: "5"
      persistentvolumeclaims: "10"
      secrets: "20"
      services: "5"


top

Understand the Primitives Used to Create Robust, Self-healing, Application Deployments

Relevant search terms for Kubernetes Documentation: replicaset, deployment, statefulset, daemonset

Kubernetes Documentation Links

• ReplicaSet
• Deployments
• StatefulSets
• DaemonSet

API Objects

• ReplicaSet - “A ReplicaSet’s purpose is to maintain a stable set of replica Pods running at any given time. As such, it is often used to guarantee the availability of a specified number of identical Pods.” ReplicaSets are created by deployments.

• Deployment - Adds an additional layer of control for ReplicaSets via rollouts and rollbacks

• StatefulSet - “Manages the deployment and scaling of a set of pods and provides guarantees about the ordering and uniqueness of these pods.” Pods created by a StatefulSet are all based on the same container spec; however, in contrast with the Deployment, the StatefulSet maintains a distinct identity for each pod.

  StatefulSets are valuable for applications that require one or more of the following.

  • Stable, unique network identifiers.
  • Stable, persistent storage.
  • Ordered, graceful deployment and scaling.
  • Ordered, automated rolling updates.

  In the above, stable is synonymous with persistence across Pod (re)scheduling. If an application doesn’t require any stable identifiers or ordered deployment, deletion, or scaling, you should deploy your application using a workload object that provides a set of stateless replicas. Deployment or ReplicaSet may be better suited to your stateless needs.

• DaemonSet - Manages scenarios such as logging or monitoring where it is necessary to have one pod running on all nodes or a subset of nodes. As nodes are added to the cluster or removed from the cluster the Daemonset automatically creates a new pod on each new node and removes a pod from each node that is removed.

top

Understand Deployments and How to Perform Rolling Update and Rollbacks

Relevant search terms for Kubernetes Documentation: deployment

Kubernetes Documentation Links

• Deployments

Concepts

• When a deployment is created, the deployment controller creates a ReplicaSet which creates the corresponding pods.
• A change made to a deployment resource triggers a rollout which is managed by the deployment controller. The controller manages the changes by creating a new ReplicaSet with the changes applied and then adding new pods to it while removing Pods from the old ReplicaSet at a controlled rate. The change creates a new revision of the deployment. A rollout can be paused which enables the operator to make multiple changes to the deployment configuration without triggering additional rollouts.
• If the new deployment is not stable then it is possible to rollback to a previous revision of the deployment.
• Deployments can be scaled up and down.
• The kubectl rollout command can be used with deployments, daemonsets, and statefulsets. However, only deployments can be paused and resumed.
• To document changes made to objects as annotations use the --record=true flag (or simply add the --record flag).

Relevant Commands

Create a deployment called “my-dep” using the nginx image with 3 replicas running on port 8080 and pass the “date” command

kubectl create deployment my-dep --image=nginx \
--replicas=3 --port=8080 -- date

Generate a file called “deploy.yml” for a deployment called “my-dep” using the nginx image with 3 replicas

kubectl create deployment my-dep --image=nginx \
--replicas=3 --dry-run=client -o yaml > deploy.yml

NOTE: useful in cases where additional changes to the definition are required prior to creating the deployment

Update the image used in a deployment called “nginx-deployment”

kubectl set image deployment/nginx-deployment \
nginx=nginx:1.16.1

Check the status for the rollout of a deployment called nginx

kubectl rollout status deployment/nginx

Show the rollout history for a deployment called “abc”

kubectl rollout history deployment/abc

Show the details of revision 3 of a deployment called “abc”

kubectl rollout history deployment/abc --revision=3

Rollback to the previous revision of a deployment called “abc”

kubectl rollout undo deployment/abc

Rollback to revision 3 of a deployment called “abc”

kubectl rollout undo deployment/abc --to-revision=3

Pause deployment tracking for the deployment called “nginx” so that several changes can be made without triggering the creation of new ReplicaSets.

kubectl rollout pause deployment/nginx

Resume deployment tracking for the deployment called “nginx” and trigger the creation of a new revision and ReplicaSet.

kubectl rollout resume deployment/nginx

Perform a rolling restart for a deployment called “nginx”. Each pod in the deployment is terminated one by one forcing the replicaset to create new replacement pods.

kubectl rollout restart deployment/nginx

top

Know How to Scale Applications

Relevant search terms for Kubernetes Documentation: scale, horizontalpodautoscaler, averagevalue

Kubernetes Documentation Links

• ReplicaSet
• Deployments
• StatefulSets
• Scale Your App
• Scale a StatefulSet
• Horizontal Pod Autoscaling
• HorizontalPodAutoscaler Walkthrough

API Objects

• HorizontalPodAutoscaler - (shortname hpa) “automatically updates a workload resource (such as a Deployment or StatefulSet), with the aim of automatically scaling the workload to match demand.”

Concepts

• You can change the number of replicas for a replica set, deployment, or stateful set manually by using the kubectl scale command or by modifying the manifest using kubectl edit.
• You can also employ the Kubernetes Horizontal Pod Autoscaler to automatically scale the number of pods up or down to match demand based on specified metrics such as CPU percentage thresholds or memory utilization.
• In order to leverage the Horizontal Pod Autoscaler, it is necessary to do the following:
  • Deploy the Metrics Server to the cluster. “The Kubernetes Metrics Server collects resource metrics from the kubelets in your cluster, and exposes those metrics through the Kubernetes API, using an APIService to add new kinds of resource that represent metric readings. "
  • Define resource requests for the containers in the Pods that the Horizontal Pod Autoscaler will work with. “Please note that if some of the Pod’s containers do not have the relevant resource request set, CPU utilization for the Pod will not be defined and the autoscaler will not take any action for that metric. "
• If you create a Horizontal Pod Autoscaler using the kubectl autoscale command then the only metric you can apply during creation is the cpu-percent metric.
• If you want to introduce an additional metric then you will need to either:
  • Create a manifest file for the Horizontal Pod Autoscaler containing multiple metrics and apply it
  • Create the HPA using the kubectl autoscale command and then edit the resource after creation using thekubectl edit command
  • Create the resource and then extract the manifest using kubectl get hpa my-hpa -o yaml > hpa.yml, update the manifest to add additional metrics, and then apply the updated manifest.

Relevant Commands

Scaling Deployments, Stateful Sets, or Replica Sets Manually

Scale a Replica Set (alias rs) to 5 replicas

kubectl scale --replicas=5 rs/web

Scale a Deployment called “redis” to five replicas only if it currently has three replicas

kubectl scale --current-replicas=3 --replicas=5 deployment/redis

Scaling Deployments, Statefulsets, or Replica Sets Automatically Using the Horizontal Pod Autoscaler

Step 1: Create a YAML manifest for a deployment

kubectl create deployment my-dep --image=nginx \
--replicas=3 --dry-run=client -o yaml > deploy.yml

Step 2: Update the spec section of the deploy.yml file to add resource requests for cpu and memory which are a necessary prerequisite for the horizontal pod autoscaler

apiVersion: apps/v1
kind: Deployment
metadata:
  name: my-dep
spec:
  replicas: 3
  selector:
    matchLabels:
      app: my-dep
  template:
    metadata:
      labels:
        app: my-dep
    spec:
      containers:
      - image: nginx
        name: nginx
        resources:
          requests:
            cpu: "0.5"
            memory: "200Mi"

Step 3: After updating the deploy.yml file with the changes to the resources section, create the deployment

kubectl apply -f deploy.yml

Step 4: Create a Horizontal Pod Autoscaler called “my-dep”

kubectl autoscale deployment my-dep --min=2 --max=5 --cpu-percent=80

Step 5: Generate a manifest file for the “my-dep” Horizontal Pod Autoscaler

kubectl get hpa my-dep -o yaml > hpa.yml

Step 6: Modify the Manifest to include an additional metric (memory)

apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: my-dep
  namespace: default
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: my-dep
  minReplicas: 2
  maxReplicas: 5
  metrics:
  - type: Resource
    resource:
      name: cpu
      target:
        averageUtilization: 80
        type: Utilization
  - type: Resource
    resource:
      name: memory
      target:
        type: AverageValue
        averageValue: 1Gi

Step 7: Deploy the updated manifest for the Horizontal Pod Autoscaler

kubectl apply -f hpa.yml

top

Use ConfigMaps and Secrets to Configure Applications

Relevant search terms for Kubernetes Documentation: configmap, secret

Kubernetes Documentation Links

• ConfigMaps
• Configure a Pod to Use a ConfigMap
• Volumes: ConfigMaps
• Secrets
• Managing Secrets using Kubectl
• Distribute Credentials Securely Using Secrets
• Volumes: Secrets

API Objects

• ConfigMap - “an API object used to store non-confidential data in key-value pairs.”
• Secret - “an object that contains a small amount of sensitive data such as a password, a token, or a key. "

Concepts

• Config maps and Secrets store key / value pairs in Kubernetes so that the data is not stored in containers.
• Config map data is stored in plain text. However, the values for Secrets are base64 encoded. Secrets store confidential data like passwords. However, Kubernetes does not encrypt the data by default; it is only base64 encoded.
• Config maps and Secrets can be created by
  • Passing literal values as arguments to the kubectl create command
  • Passing a path to a file or directory to the kubectl create command
  • Creating a YAML manifest and then using the kubectl apply -f filename.yml command
• There are several different ways expose the data stored in a config map or a secret to a container running in a Pod
  • All or specific key / value pairs from a config map or a secret can be exposed to a container as environment variables
  • After exposing config map or secret value pairs as environment variables, they can be added to Pod Commands
  • All or specific key / value pairs from a config map or a secret can be exposed to a container as files via volumes
  • A process running in the container can pull the data using the Kubernetes API
• Container registry credentials can also be stored in secrets and pulled by kubectl to pull pod images

Relevant Commands

Creating Config Maps

Create a config map by specifying values.

kubectl create configmap smtp-config \
--from-literal=smtp-server=smtp1.domain.com \
--from-literal=smtp-port=587 \
--from-literal=smtp-protocol=tls

Create a config map from the files in a folder.

kubectl create configmap env-test \
--from-file=env/test-env-values

Creating Secrets

Create a Secret by specifying values.

kubectl create secret generic smtp-cred \
--from-literal=login=smtpuser \
--from-literal=pass=p@ss

Create a Secret from the files in a folder.

kubectl create secret generic auth-test-params \
--from-file=auth/test

Injecting Config Maps Data into Containers as Environment Variables

To expose all of the key / value pairs from a config map in the Pod YAML resource definition as environment variables use envFrom in the spec and the configMapRef and name to reference the config map.

apiVersion: v1
kind: Pod
metadata:
  name: my-web-app
spec:
  containers:
    - name: web-app
      image: nginx
      envFrom:
      - configMapRef:
          name: my-configmap

To expose specific key / value pairs from a config map in the Pod YAML resource definition as environment variables use env in the spec and the configMapKeyRef with the key and the name to reference specific keys in the config map. “You can use ConfigMap-defined environment variables in the command and args of a container using the $(VAR_NAME) Kubernetes substitution syntax.”

apiVersion: v1
kind: Pod
metadata:
  name: animal-web-app
spec:
  containers:
    - name: animal-web-app
      image: my-animal-web-app
      command: [ "/bin/echo", "$(DOG_BREED) $(CAT_BREED)" ]
      env:
        - name: DOG_BREED
          valueFrom:
            configMapKeyRef:
              name: dog-beagle-configmap
              key: breed
        - name: CAT_BREED
          valueFrom:
            configMapKeyRef:
              name: cat-persian-configmap
              key: breed

Injecting Config Maps Data into Containers as Files

To expose all of the key / value pairs from a config map in the Pod YAML resource definition as files add a volumes section to the spec which references the conifgMap and then add a volumeMounts section to the container spec with the name of the volume and the mountPath.

apiVersion: v1
kind: Pod
metadata:
  name: my-web-app
spec:
  containers:
    - name: web-app
      image: nginx
      volumeMounts:
      - name: config-volume
        mountPath: /etc/config
  volumes:
    - name: config-volume
      configMap:
        name: special-config

To expose specific key / value pairs from a config map in the Pod YAML resource definition as files add a volumes section to the spec which references the conifgMap, add items, reference the desired keys, and then add a volumeMounts section to the container spec with the name of the volume and the mountPath.

apiVersion: v1
kind: Pod
metadata:
  name: animal-web-app
spec:
  containers:
    - name: animal-web-app
      image: my-animal-web-app
      volumeMounts:
      - name: dog-volume
        mountPath: /etc/config
  volumes:
    - name: dog-volume
      configMap:
          name: dog-beagle-configmap
          items:
          - key: breed
            path: breed
          - key: temperment
            path: temperment

Injecting Secret Data into Containers as Environment Variables

To expose all of the key / value pairs from a secret in the Pod YAML resource definition as environment variables use envFrom in the spec and the secretRef and name to reference the secret.

apiVersion: v1
kind: Pod
metadata:
  name: my-web-app
spec:
  containers:
    - name: web-app
      image: nginx
      envFrom:
      - secretRef:
          name: my-secret

To expose specific key / value pairs from a secret in the Pod YAML resource definition as environment variables use env in the spec and the secretKeyRef with the key and the name to reference specific keys in the secret. “You can use secret-defined environment variables in the command and args of a container using the $(VAR_NAME) Kubernetes substitution syntax”

apiVersion: v1
kind: Pod
metadata:
  name: animal-web-app
spec:
  containers:
    - name: animal-web-app
      image: my-animal-web-app
      command: [ "/bin/echo", "$(SECRET_DOG) $(SECRET_CAT)" ]
      env:
        - name: SECRET_DOG
          valueFrom:
            secretKeyRef:
              name: dog-beagle-Secret
              key: breed
        - name: SECRET_CAT
          valueFrom:
            secretKeyRef:
              name: cat-persian-secret
              key: breed

Injecting Secret Data into Containers as Files

To expose all of the key / value pairs from a secret in the Pod YAML resource definition as files add a volumes section to the spec which references the Secret and then add a volumeMounts section to the container spec with the name of the volume and the mountPath.

apiVersion: v1
kind: Pod
metadata:
  name: my-web-app
spec:
  containers:
    - name: web-app
      image: nginx
      volumeMounts:
      - name: animal-volume
        mountPath: /etc/config
        readonly: true
  volumes:
    - name: animal-volume
      secret:
        secretName: animal-secret

To expose specific key / value pairs from a secret in the Pod YAML resource definition as files add a volumes section to the spec which references the secret, add items, reference the desired keys, and then add a volumeMounts section to the container spec with the name of the volume and the mountPath.

apiVersion: v1
kind: Pod
metadata:
  name: animal-web-app
spec:
  containers:
    - name: animal-web-app
      image: my-animal-web-app
      volumeMounts:
      - name: animal-secret-volume
        mountPath: /etc/config
        readOnly: true
  volumes:
    - name: animal-secret-volume
      secret:
          secretName: animal-secret
          items:
          - key: animal-login
            path: animal-login
          - key: animal-password
            path: animal-password

top

Awareness of Manifest Management and Common Templating Tools

Relevant search terms for Kubernetes Documentation: kustomize, manage kubernetes objects, kubectl commands

Kubernetes Documentation Links

• Manage Kubernetes Objects
• Declarative Management of Kubernetes Objects Using Kustomize
• kubectl reference docs

Concepts

• There are several ways to create kubernetes objects using kubectl

  • Create objects imperatively using the kubectl create and the name of the object (e.g., deployment, service, etc.) and including the supported parameters required to create the object.

  • Create objects declaratively using the kubectl apply -f filename.yaml where the file contains the yaml resource definitions for one or more resources.

  • Creating objects declaratively via kustomize using the kubectl apply -k <kustomization-directory>. The <kustomization directory> must have a manifest file called kustomization.yml which can include:

    • A configMapGenerator which can reference a file containing the keys and values for a configmap, a file with environment parameters, or the literal key value pairs.
    • A secretGenerator which can reference a file containing the keys and values for a secret, or the literal key value pairs.
    • A resources list which references the yaml manifests for additional resources which will be created by the process. All of the resources listed in the kustomization.yml must exist in the same folder.
    • A generatorOptions section which can define labels or annotations which should be applied to all config maps and secrets and can also disable the suffix that is automatically applied to generated config maps and secrets with the option disableNameSuffixHash: true.
    • There are also additional parameters which when included will be applied to all created resources including namespace, namePrefix, nameSuffix, commonLabels, and commonAnnotations.

  • The names of the config maps or secrets defined in the kustomization.yml can be used in the resource files defined in kustomization.yml file. In this case, the generated YAML will contain the config map or secret resources as well as the other resources which reference them. The references to the config maps or secrets will all be updated in the other resource definitions to match correctly.

  • Run the kubectl kustomize <kustomization folder> to generate a YAML manifest containing all of the resources that will be created.

top

And that’s a wrap for this topic.

Return to the series overview page
